Fabrication benefits
- Use of identical components for different basic depths: reduced number of components and simplified logistics and storage
- Uses system components from the Schüco AWS window system: efficient, low-cost fabrication
- System compatibility: can be integrated in Schüco façade systems
Technical information
System basic depth65 mm
Uf value of frame (≥)2.9 W/(m²·K)
Max. height3000 mm
Max. width1400 mm
Max. glass/panel thickness45 mm
Area of applicationResidential projects, Residential projects, Commercial projects
Air permeabilityClass 2
WatertightnessClass 5A
Wind load resistanceClass C3
Burglar resistanceUp to RC3
Impact resistanceClass 1
Max. vent weight200 kg
Min.-max. height…3000 mm
Min.-max. width…1400 mm
Min. face width147 mm
Min.-max. glass/panel thickness4…45 mm
Type of designSingle-vent, Double-vent, Single-vent and side section, Double-vent and side section, Single-vent with toplight, Double-vent with toplight, Single-vent with toplight and side section, Double-vent with toplight and side section, Single-vent with side section, right, Single-vent with side section, left, Single-vent with side section, right and left, Single-vent with side section and toplight, Double-vent with side section, right, Double-vent with side section, left, Double-vent with side section, right and left
Vent optionAll around, Sill rail profile, Adjustable sill, Flush-fitted, Face-fitted
Infill typeInsert panel infill, Door infill, leaf enclosing on one side, Door infill, leaf-enclosing on two sides
Door thresholdAluminium, PVC-U, Automatic door gasket, Flat door threshold
Opening typeSide-hung, Inward and outward, Single and double-vent
DIN directionDIN LH / RH
Mechanical strengthClass 3
Proof of durabilityClass 8
Behaviour between different climatesClass 3(d),3(e)
Max. sound reduction Rwp43 dB(A)
CE markingYes
CAD data
Planning principles
System drawings
Planning principles
System drawings
Planning principles
Test documents
1-3 of 3
| Document type | Test type | Result | Classification | Document no. / Download |
|---|---|---|---|---|
| Prüfbericht | Dauergebrauchstauglichkeit | Heavy duty | BS EN 1192 | View onlineDownload (pdf, 1.8 MB) |
| Kurzbericht | Luftdurchlässigkeit Schlagregendichtheit Windwiderstandsfähigkeit |
Klasse 2 Klasse 4A Klasse C2 / B2 |
EN 12207 EN 12208 EN 12210 |
View onlineDownload (pdf, 140.1 KB) |
| Kurzbericht | Windwiderstandsfähigkeit Schlagregendichtheit Luftdurchlässigkeit |
Klasse C2 / B2 Klasse 3A Klasse 2 |
EN 12210 EN 12208 EN 12207 |
View onlineDownload (pdf, 140.0 KB) |
