Fabrication benefits
- Special vent frame profile for the use of adhesive technology
- Easy-access threshold
- High-quality EPDM functional gaskets machine-rolled in the factory, can be welded
- Due to a special, patented technology for welding the profiles, the gaskets do not require any additional processing
- Glazing bridge with self-locating clamp for secure and easy installation
- Cliphook on the double-vent profiles as a positioning aid for simple installation and central screw connection
- Due to 5 mm gasket clearance between the outer and vent frames, the vent rebate gasket does not need to be notched in the turn/tilt mechanism pivot area
Technical information
System basic depth82 mm
Uf value of frame (≥)1.1 W/(m²·K)
Max. height2350 mm
Max. width1100 mm
Max. glass/panel thickness52 mm
Surface finishesTopAlu, Decorative foils, AutomotiveFinish
Air permeabilityClass 2
WatertightnessClass 5A
Wind load resistanceClass C2 / B2
Burglar resistanceUp to RC2
Min.-max. height1800…2350 mm
Min.-max. width700…1100 mm
Min. face width120 mm
Min.-max. glass/panel thickness24…52 mm
Barrier-free (≤) 20 mmYes
Zero-level thresholdYes
Door thresholdAutomatic door gasket, Easy-access door threshold
Opening typeSide-hung, Inward and outward
