FABRICATION BENEFITS
- Simple and secure fabrication – even when individual unit geometries are very complicated – by means of CNC processing of the profiles, system construction with wide tolerances and individualised system components
- Automatic, detailed design of the units with integrated plausibility check: parametric system modelling with substantial time savings in planning
- Non-series components are automatically generated in the planning tools and are available as system articles (mass customisation)
- Full Schüco 3D fabrication support, including machine control: Reliable assurance of efficiency and level of quality of the profile processing details (file-to-factory) without interface problems
TECHNICAL INFOS
- Uf value of frame (≥)
-
- 0.41 W/(m²·K)
- Max. glass/panel thickness
-
- 60 mm
- Air permeability
-
- AE
- Watertightness
-
- RE 1200
- Wind load resistance
-
- 2.0/3.0 [kN/m²]
- CE marking
-
- Nein
- Surface finishes
-
- Powder
- Anodised
- Paint
- Min.-max. glass/panel thickness
-
- 28…60 mm
- Suitable for safety barrier loading
-
- Ja
- Impact resistance
-
- I5/E5
- Max. height
-
- 4000 mm
- Max. width
-
- 1500 mm
- SYSTEM / MATERIAL
-
- Aluminium
- FAÇADE TYPE
-
- Unitised façade
- All-glass façade
- ENERGY
-
- Highly thermally insulated
- Thermally insulated
- DESIGN
-
- Parametric
- Structural glazing
- Max. weight
-
- 500 kg
- AAMA certified
-
- Yes
- Min. glass/panel thickness
-
- 28 mm
- Face width, inside
-
- 72.5 mm
- Total width of unit
-
- 1500 mm
- Total height of unit
-
- 4000 mm
- Integrated ventilation
-
- Nein
- European Technical Assessment
-
- Nein
- Standards
-
- EN ISO 10077
- DIN EN 13830
- Installation angle
-
- 90°
- Drainage
-
- Ja
- Drainage levels
-
- 1
- Recyclable
-
- Ja
- Max. unit weight
-
- 500 kg
