FABRICATION BENEFITS
- Patented fittings installation: proven piercing technology for simple connection of connecting cables
- Virtually no machining required on the profile
- Compatible with toplights or sidelights from the Schüco AWS 50 window system range
- Vents that can be freely accessed and opened are easy to install
TECHNICAL INFORMATION
- System basic depth
-
- 39 mm
- Min. face width
-
- 70 mm
- Max. glass/panel thickness
-
- 28 mm
- Max. vent width
-
- 1700 mm
- Max. vent height
-
- 2700 mm
- Air permeability
-
- Class 3
- Watertightness
-
- Class 5A
- Burglar resistance
-
- Up to RC1 N
- Wind load resistance
-
- Class C3
- Uw value of window (≥)
-
- 1.8 W/(m²·K)
- Max. vent weight
-
- 160 kg
- Min.-max. vent width
-
- …1700 mm
- Area of application
-
- External use
- Residential projects
- Commercial projects
- Surface finishes
-
- Powder
- Paint
- Min.-max. glass/panel thickness
-
- 24…28 mm
- Vent frame face width
- SYSTEM / MATERIAL
-
- Aluminium
- ENERGY
-
- Thermally insulated
- System type
-
- Sliding systems
- Opening type
-
- Type 2A/1
- Number of tracks
-
- Double track
- Operating type
-
- electric
- Min. face width of interlocking section
-
- 39 mm
- Power supply
-
- 24 V
