Window System AWS 60

Wide variety of window solutions to meet the requirements of international markets

The thermally insulated standard window system for the 60 mm basic depth offers an extensive range of solutions for a variety of building envelope requirements.

It is based on the functional and design properties of the aluminium system: perfectly tailored components combine benefits such as narrow face widths and concealed, standard manual or electromechanical fittings for inward and outward-opening windows.

The high level of flexibility of the system ensures a variety of uses as a punched opening, ribbon window or façade insert unit, as well as in combination with Schüco door systems.

An additional benefit for specifiers and architects is the wide range of opening types such as side-hung and turn/tilt vents, bottom-hung toplights or barrier-free window doors.

An outward-opening window design with centre gasket is also available as a double-vent window with burglar resistance in accordance with test procedure PAS 24.

As part of the Schüco AWS system platform, the window system offers a wide range of profiles, including corner mullions, structural mullions, symmetrical and asymmetrical mullions, as well as a number of design variations and additional combination options, such as with Schüco sun shading and ventilation systems.

Schüco AWS 60 thereby sets standards in terms of planning flexibility and offers attractive window solutions specifically for meeting the requirements of international markets.


Technical information

System basic depth60 mm
Min. face width91 mm
Uf value of frame (≥)1.7 W/(m²·K)
Max. glass/panel thickness50 mm
Max. vent width1700 mm
Max. vent height2500 mm
Max. sound reduction Rwp47 dB(A)
Air permeabilityClass 4
WatertightnessClass 9A
Burglar resistanceUp to RC2
Wind load resistanceClass C5 / B5
CE markingYes
Total basic depth70 mm
Width of vent frame70 mm
Max. vent weight250 kg
Min.-max. vent height540…2500 mm
Min.-max. vent width470…1700 mm
Outer frame face width51 mm
Vent frame face width40 mm
Max. face width of mullion250 mm
Min.-max. face width of mullion76…250 mm
Max. face width of meeting stile163 mm
Min.-max. face width of meeting stile148…163 mm
Min.-max. glass/panel thickness11…50 mm
Barrier-free (≤) 20 mmYes
Area of applicationExternal use, Residential projects, Residential projects, Commercial projects
Shear bondYes
Concealed fittings systemYes
Surface finishesPowder, Anodised, Paint
Glass compositionTriple glazing
Operating forcesClass 1
Barrier-free operating forces in accordance with DIN 18040Yes
Opening type: TipTronic, inward-openingTurn/tilt, Side-hung, Bottom-hung, Toplight
Opening type: manual, outward-openingSide-hung, Double-vent side-hung / side-hung, Projected top-hung, Projected side-hung, Horizontal pivot, Vertical pivot
Opening type: manual, inward-openingTurn/tilt, Side-hung, Bottom-hung, Double-vent turn/tilt / side-hung, Double-vent side-hung / side-hung, Tilt/slide, Toplight, Horizontal pivot, Vertical pivot, Tilt-before-turn
Opening angle180 °
Mechanical strengthClass 4
Proof of durabilityClass 3
Corrosion protection class for fittingsClass 5
Uw value of window (≥)1 W/(m²·K)
Ug value of glass (≤)0.3 W/(m²·K)
Drainage levels3
Integrated sun shadingYes
Security glazingYes
Suitable for safety barrier loadingYes
Certificatescradle2cradle SILVER


[C] Basic depth 60 mm

View online

[E] Schüco AWS 60

View online

Order manual 1-3 – Window fittings

View onlineDownload

[Da] Schüco AWS 60

View online

Fabrication manual 1-3 – Window fittings

View onlineDownload

Mechanical security with Schüco aluminium systems

View onlineDownload

Specification texts

Schüco AWS 60, thermally insulated aluminium window system
With 60 mm basic depth.

Design features:
Face-fitted vent frame on the room side rebated by 10 mm from the frame edge, flush-fitted on the outside.
The centre gasket is located in the area of the insulation zone.
The system must be fitted with square glazing beads.
The glazing beads are installed with plastic clips to compensate tolerances.

Profile basic depths:
Outer frame, mullion, transom 60 mm
Vent frame 70 mm

Profile face widths:
Outer frame, bottom 94 mm
Outer frame, side and top 79 mm
Mullion 94 mm
Transom 94 mm
Vent frame (window) 41 mm
Vent frame (window door) 61 mm
Double-vent profile (window) 67 mm


CAD data

Planning principles

View online

System drawings

View online

Rule details

View online

Test documents

Document type Test type Result Classification Document no. / Download
Prüfbericht Pendelschlagversuch voll absturzsichernd Kategorie A View onlineDownload (pdf, 5.7 MB)
Prüfzeugnis Stoßfestigkeit 300 Klasse 2 View onlineDownload (pdf, 648.3 KB)
Prüfzeugnis Einbruchhemmung einbruchhemmendes Fenster RC 2 View onlineDownload (pdf, 188.7 KB)
Prüfzeugnis Einbruchhemmung einbruchhemmendes Fenster RC 2 View onlineDownload (pdf, 252.9 KB)
Prüfzeugnis Schallmessung 46 Klasse 4 (alte Norm) View onlineDownload (pdf, 414.6 KB)
Prüfzeugnis Einbruchhemmung einbruchhemmendes Element RC 2 / RC 2N View onlineDownload (pdf, 172.5 KB)
Prüfzeugnis Schallmessung 37 Klasse 3 (alte Norm) View onlineDownload (pdf, 410.8 KB)
Prüfzeugnis Schallmessung 37 Klasse 3 (alte Norm) View onlineDownload (pdf, 412.1 KB)
Prüfzeugnis Schallmessung 42 Klasse 4 (alte Norm) View onlineDownload (pdf, 363.4 KB)
Prüfzeugnis Schallmessung 46 Klasse 4 (alte Norm) View onlineDownload (pdf, 413.2 KB)
1-10 of 102
