FABRICATION BENEFITS
- Comprehensive platform for the integration, control and monitoring of the mechatronic Schüco units
- Open interface for maximum variety. Schüco BSC can be connected to open building management systems such as KNX or BACnet as well as external smart home systems such as Amazon Alexa
- One piece of software for all functions: Uniform system platform for configuration, commissioning and linking all mechatronic Schüco units that can be connected
- Thanks to a cloud connection, all units and devices can be accessed securely and remotely too. The advantage of this is that you can quickly respond to customer requests as you can access the system directly from anywhere
- Schüco dashboard: An individual overview of all Schüco BSC systems installed in projects in one web interface
TECHNICAL INFOS
Area of application
- Internal use
FUNCTIONS
- Easy operation
- Motorisation
Ambient temperature
- -10°C bis +60°C
Function
- Easy operation
Radio control
- Ja
Rated current
- 1.5 A
Relative air humidity
- 0,93
Protection rating IP
- IP 20 (installed in electrical distributor)
Protection class
- Class III
App operation
- IOS
BSC compatible
- Ja
Can be integrated in
- KNX
- BACnet
- IP
Installation type
- Top hat rail
Module distribution box
- min, 8TE
Communication method
- Schüco BUS with gateways for connection to building management systems
TENDER SPECIFICATIONS
PREVIEW SPECIFICATION
Platform for networking the different units of the building envelope with one another.
Buttons and sensors can be connected by means of a control component and additional components. The system has interfaces to KNX, BACnet and IP. It is possible to access the system remotely via the web interface – following a security prompt on the control component. An associated app can be used to control all units from a mobile device as well as monitor their status.
The entire system is configured by means of the corresponding commissioning software. Unit-specific settings can be made, and buttons, sensors and automatic functions (e.g. night-time cooling) can be set.
Automation Manager
Required in order to intelligently control up to 30 units e.g. Schüco TipTronic Simply Smart windows or Schüco ASE 60/80 TipTronic sliding units.
Functions
Intelligent central control unit which evaluates and regulates Schüco units e.g. TipTronic SimplySmart, sensors and control units. The Schüco units communicate via the Schüco unit bus.
The inputs and outputs on the Automation Manager are pre-configured but can be changed. Sensors and buttons/switches can be connected directly. The default input for the wind & rain sensor ensures that the units are closed by means of a notification. The inputs for buttons/switches provide pre-configured group functions. The display on the Automation Manager or the Schüco Automation Engineering Tool software can be used to freely configure the inputs and outputs as well as view event lists, among other things.
The following options are available for using the Schüco Automation Engineering Tool software on a computer:
– Direct connection via the integrated mini USB interface on the Automation Manager
– By means of WiFi via the IP gateway
– Remote support by means of internet access via the IP gateway
Windows Vista Service Pack 2 or higher must be installed in order to use the software.
Optional add-ons in the top hat rail design can be connected to the Automation Manager. The add-ons communicate via the Schüco device bus. The add-ons make it possible to use additional buttons / switches / sensors or to communicate with building management systems. The electrical connection between the Automation Manager and add-ons is made by means of a bus connector in the mounting rail.
The integrated display can be used to create simple links between operating panels and units, so that fast initial commissioning is possible without a PC too.
Maximum cable length of the unit bus is 500 metres when laid in a line.
Automation Manager features
Series installation device with 4 modules
Connection using plug-in terminal screws
Mini USB for connection to a computer
Required for connection of the following add-ons: button interface, device coupler, sensor interface as well as all gateways (IP & building management systems)
Power supply by means of Schüco power pack 263 099
4 pre-configured / configurable inputs for buttons/switches and sensors
1 pre-configured / configurable output
Contents of delivery
Automation Manager
Quick start guide
Complete operating instructions as a download
Schüco Automation Engineering Tool software as a download
Technical data
Power supply: 24 V DC
Bus connection (1): Schüco device bus (via top hat rail connector)
Bus connection (2): Schüco unit bus
Number of Schüco TipTronic: Max. 30
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 4 modules (71.2 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 245 Automation Manager (BSC)
Button interface
Functions
Enables the connection of 16 buttons or 8 switches to the freely configurable inputs. Status LED indicates the system is ready for operation. Requires Schüco Automation Manager for operation. Communication with the Automation Manager by means of the Schüco device bus. Configuration via the display of the Automation Manager or via the Schüco Automation Engineering Tool software.
Up to four button interfaces can be operated on one Automation Manager. Can be combined with a KNX gateway, for example. The power is supplied by means of the Schüco device bus; an additional power pack is not required.
Characteristics
Series installation device with 3 modules
Connection using plug-in terminal screws
Prepared for connection to Schüco Automation Manager 263245 via device bus
A maximum of four button interfaces can be connected to one Automation Manager
Contents of delivery
Button interface
Operating instructions
Technical data
Power supply: 24 V DC (via the Automation Manager)
Bus connection: Schüco device bus via bus connector in the mounting rail
Number of momentary-contact / maintained-contact switches: Max. 16 momentary-contact switches or 8 maintained-contact switches
Output: 2 outputs can be configured via the Automation Manager
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 3 modules (53.4 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 246 button interface (BSC)
KNX gateway
Functions
The Automation Manager is KNX-compatible via the KNX gateway. The KNX gateway enables easy integration of the Automation Manager in the building management system. The Automation Manager and KNX gateway communicate via the Schüco device bus. Configuration from ETS 4. No additional power pack required.
Characteristics
Series installation device with 2 modules
24 V DC power supply (via bus connector in the mounting rail)
Prepared for connection to Schüco Automation Manager
The KNX gateway is an officially licensed product
Contents of delivery
KNX gateway in the series installation device with 2 modules
Operating instructions
Product database for ETS4 and ETS5 (as download)
Technical data
Power supply: 24 V DC
Bus connection (1): KNX TP (twisted pair)
Bus connection (2): Schüco device bus via bus connector in the mounting rail
Number of Automation Managers Max. 1
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 2 modules (35.6 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 243 KNX gateway (BSC)
RS-485 hub
Function:
Enables a star wiring structure to change to a linear wiring structure for the Schüco unit bus (similar to individual branches of a tree). The RS-485 hub electrically splits the Schüco unit bus into up to four individual strands and improves the signal for long cable lengths.
Characteristics
Top hat rail housing 72 mm * 122 mm * 35 mm
Power supply 24 V DC
Terminating resistors can be switched internally
Automatic recognition of the transfer rate
Contents of delivery
RS-485 hub
Terminating resistor
Operating instructions
Technical data
Power supply: 24 V DC (+10 V DC to 30 V DC)
Bus connection (1): 1 RS-485 input (from the Automation Manager)
Bus connection (2): 4 RS-485 outputs, potential-free, isolated (to the units)
Protection rating: IP 20
Dimensions (W x H x D): 72 mm * 122 mm * 35 mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 256 RS-485 hub (BSC)
Device coupler
Function:
Enables the button interfaces, KNX gateway, IP gateway, BACnet gateway and sensor interface to be installed away from the Automation Manager Communication by means of the Schüco device bus. Installation in a different location possible up to 500 m.
Characteristics
Series installation device with 1 module
Power supply 24 V DC
Prepared for connection to Schüco Automation Manager as well as Schüco unit bus and Schüco device bus
Contents of delivery
Device coupler in series installation device with 1 module
Instruction leaflet
Technical data
Power supply: 24 V DC
Bus connection (1): Schüco unit bus
Bus connection (2): Schüco device bus
Number of Automation Managers: 1
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 1 module (17.8 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 254 device coupler BSC
Top hat rail connector
Function:
Top hat rail module which can be used to transfer the cables of the Schüco device bus to another top hat rail. Individual wiring is therefore not necessary.
Characteristics
Adapter cable for operating the system using multiple top hat rails
Rated voltage 24 V DC
Prepared for connection to Schüco Building Skin Control (BSC) components on the Schüco device bus
Adapter cable meets the system standard
Contents of delivery
1 x top hat rail connector
Instruction leaflet
Technical data
Power supply: Passive adapter cable
Bus connection (1): For extending the Schüco device bus (top hat rail adapter)
Number of Automation Managers: Max. 1
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): Plugs suitable for Schüco device bus. Cable length 300 mm
Installation: On top hat rail adapter
Manufacturer: Schüco International KG
Type: 263 255 top hat rail connector (BSC)
IP gateway
Functions
Connection for integration of Schüco TipTronic units (AWS TipTronic SimplySmart, AES 60/80 TipTronic) in the network of the building and in the Schüco Cloud as well as for control of the Schüco TipTronic SimplySmart units by means of an app. The IP gateway enables the control of connected units by means of voice command (Amazon Alexa) as well as use of the Schüco Operation Dashboard. The IP gateway must be used with the Automation Manager. The Automation Manager and IP gateway communicate via the Schüco device bus. No additional power pack required.
Characteristics
Series installation device with 3 modules
Power supply 24 V DC
Prepared for connection to Schüco Automation Manager
Contents of delivery
IP gateway in the series installation device with 3 modules
Operating instructions
(Optional) WiFi antenna
Technical data
Power supply: 24 V DC
Bus connection (1): Ethernet, WLAN
Bus connection (2): Schüco device bus via bus connector in the mounting rail
Number of Automation Managers Max. 1
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 3 modules (53.4 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 302 IP gateway (BSC)
BACnet gateway
Functions
The Automation Manager is BACnet-compatible via the BACnet gateway. The BACnet gateway enables easy integration of the Automation Manager in the building management system.
The Automation Manager and BACnet gateway communicate via the Schüco device bus or the integrated WiFi connection of the BACnet gateway. No additional power pack required.
Characteristics
Series installation device with 3 modules
Power supply 24 V DC
Prepared for connection to Schüco Automation Manager
The BACnet gateway meets the official ASHRAE standard
Contents of delivery
BACnet gateway in the series installation device with 3 modules
Operating instructions
Technical data
Power supply: 24 V DC
Bus connection (1): Ethernet
Bus connection (2): Schüco device bus by means of top hat rail adapter
Number of Automation Managers 1
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 3 modules (53.4 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 299 BACnet gateway (BSC)
Sensor interface
Functions
Enables the connection of max. 4 analogue sensors to the freely configurable inputs. Status LED indicates the system is ready for operation. Requires Schüco Automation Manager. Communication with the Automation Manager by mBuilding Skin Control (BSC)
Platform for networking the different units of the building envelope with one another.
Buttons and sensors can be connected by means of a control component and additional components. The system has interfaces to KNX, BACnet and IP. It is possible to access the system remotely via the web interface – following a security prompt on the control component. An associated app can be used to control all units from a mobile device as well as monitor their status.
The entire system is configured by means of the corresponding commissioning software. Unit-specific settings can be made, and buttons, sensors and automatic functions (e.g. night-time cooling) can be set.
Automation Manager
Required in order to intelligently control up to 30 units e.g. Schüco TipTronic Simply Smart windows or Schüco ASE 60/80 TipTronic sliding units.
Functions
Intelligent central control unit which evaluates and regulates Schüco units e.g. TipTronic SimplySmart, sensors and control units. The Schüco units communicate via the Schüco unit bus.
The inputs and outputs on the Automation Manager are pre-configured but can be changed. Sensors and buttons/switches can be connected directly. The default input for the wind & rain sensor ensures that the units are closed by means of a notification. The inputs for buttons/switches provide pre-configured group functions. The display on the Automation Manager or the Schüco Automation Engineering Tool software can be used to freely configure the inputs and outputs as well as view event lists, among other things.
The following options are available for using the Schüco Automation Engineering Tool software on a computer:
– Direct connection via the integrated mini USB interface on the Automation Manager
– By means of WiFi via the IP gateway
– Remote support by means of internet access via the IP gateway
Windows Vista Service Pack 2 or higher must be installed in order to use the software.
Optional add-ons in the top hat rail design can be connected to the Automation Manager. The add-ons communicate via the Schüco device bus. The add-ons make it possible to use additional buttons / switches / sensors or to communicate with building management systems. The electrical connection between the Automation Manager and add-ons is made by means of a bus connector in the mounting rail.
The integrated display can be used to create simple links between operating panels and units, so that fast initial commissioning is possible without a PC too.
Maximum cable length of the unit bus is 500 metres when laid in a line.
Automation Manager features
Series installation device with 4 modules
Connection using plug-in terminal screws
Mini USB for connection to a computer
Required for connection of the following add-ons: button interface, device coupler, sensor interface as well as all gateways (IP & building management systems)
Power supply by means of Schüco power pack 263 099
4 pre-configured / configurable inputs for buttons/switches and sensors
1 pre-configured / configurable output
Contents of delivery
Automation Manager
Quick start guide
Complete operating instructions as a download
Schüco Automation Engineering Tool software as a download
Technical data
Power supply: 24 V DC
Bus connection (1): Schüco device bus (via top hat rail connector)
Bus connection (2): Schüco unit bus
Number of Schüco TipTronic: Max. 30
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 4 modules (71.2 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 245 Automation Manager (BSC)
Button interface
Functions
Enables the connection of 16 buttons or 8 switches to the freely configurable inputs. Status LED indicates the system is ready for operation. Requires Schüco Automation Manager for operation. Communication with the Automation Manager by means of the Schüco device bus. Configuration via the display of the Automation Manager or via the Schüco Automation Engineering Tool software.
Up to four button interfaces can be operated on one Automation Manager. Can be combined with a KNX gateway, for example. The power is supplied by means of the Schüco device bus; an additional power pack is not required.
Characteristics
Series installation device with 3 modules
Connection using plug-in terminal screws
Prepared for connection to Schüco Automation Manager 263245 via device bus
A maximum of four button interfaces can be connected to one Automation Manager
Contents of delivery
Button interface
Operating instructions
Technical data
Power supply: 24 V DC (via the Automation Manager)
Bus connection: Schüco device bus via bus connector in the mounting rail
Number of momentary-contact / maintained-contact switches: Max. 16 momentary-contact switches or 8 maintained-contact switches
Output: 2 outputs can be configured via the Automation Manager
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 3 modules (53.4 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 246 button interface (BSC)
KNX gateway
Functions
The Automation Manager is KNX-compatible via the KNX gateway. The KNX gateway enables easy integration of the Automation Manager in the building management system. The Automation Manager and KNX gateway communicate via the Schüco device bus. Configuration from ETS 4. No additional power pack required.
Characteristics
Series installation device with 2 modules
24 V DC power supply (via bus connector in the mounting rail)
Prepared for connection to Schüco Automation Manager
The KNX gateway is an officially licensed product
Contents of delivery
KNX gateway in the series installation device with 2 modules
Operating instructions
Product database for ETS4 and ETS5 (as download)
Technical data
Power supply: 24 V DC
Bus connection (1): KNX TP (twisted pair)
Bus connection (2): Schüco device bus via bus connector in the mounting rail
Number of Automation Managers Max. 1
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 2 modules (35.6 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 243 KNX gateway (BSC)
RS-485 hub
Function:
Enables a star wiring structure to change to a linear wiring structure for the Schüco unit bus (similar to individual branches of a tree). The RS-485 hub electrically splits the Schüco unit bus into up to four individual strands and improves the signal for long cable lengths.
Characteristics
Top hat rail housing 72 mm * 122 mm * 35 mm
Power supply 24 V DC
Terminating resistors can be switched internally
Automatic recognition of the transfer rate
Contents of delivery
RS-485 hub
Terminating resistor
Operating instructions
Technical data
Power supply: 24 V DC (+10 V DC to 30 V DC)
Bus connection (1): 1 RS-485 input (from the Automation Manager)
Bus connection (2): 4 RS-485 outputs, potential-free, isolated (to the units)
Protection rating: IP 20
Dimensions (W x H x D): 72 mm * 122 mm * 35 mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 256 RS-485 hub (BSC)
Device coupler
Function:
Enables the button interfaces, KNX gateway, IP gateway, BACnet gateway and sensor interface to be installed away from the Automation Manager Communication by means of the Schüco device bus. Installation in a different location possible up to 500 m.
Characteristics
Series installation device with 1 module
Power supply 24 V DC
Prepared for connection to Schüco Automation Manager as well as Schüco unit bus and Schüco device bus
Contents of delivery
Device coupler in series installation device with 1 module
Instruction leaflet
Technical data
Power supply: 24 V DC
Bus connection (1): Schüco unit bus
Bus connection (2): Schüco device bus
Number of Automation Managers: 1
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 1 module (17.8 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 254 device coupler BSC
Top hat rail connector
Function:
Top hat rail module which can be used to transfer the cables of the Schüco device bus to another top hat rail. Individual wiring is therefore not necessary.
Characteristics
Adapter cable for operating the system using multiple top hat rails
Rated voltage 24 V DC
Prepared for connection to Schüco Building Skin Control (BSC) components on the Schüco device bus
Adapter cable meets the system standard
Contents of delivery
1 x top hat rail connector
Instruction leaflet
Technical data
Power supply: Passive adapter cable
Bus connection (1): For extending the Schüco device bus (top hat rail adapter)
Number of Automation Managers: Max. 1
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): Plugs suitable for Schüco device bus. Cable length 300 mm
Installation: On top hat rail adapter
Manufacturer: Schüco International KG
Type: 263 255 top hat rail connector (BSC)
IP gateway
Functions
Connection for integration of Schüco TipTronic units (AWS TipTronic SimplySmart, AES 60/80 TipTronic) in the network of the building and in the Schüco Cloud as well as for control of the Schüco TipTronic SimplySmart units by means of an app. The IP gateway enables the control of connected units by means of voice command (Amazon Alexa) as well as use of the Schüco Operation Dashboard. The IP gateway must be used with the Automation Manager. The Automation Manager and IP gateway communicate via the Schüco device bus. No additional power pack required.
Characteristics
Series installation device with 3 modules
Power supply 24 V DC
Prepared for connection to Schüco Automation Manager
Contents of delivery
IP gateway in the series installation device with 3 modules
Operating instructions
(Optional) WiFi antenna
Technical data
Power supply: 24 V DC
Bus connection (1): Ethernet, WLAN
Bus connection (2): Schüco device bus via bus connector in the mounting rail
Number of Automation Managers Max. 1
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 3 modules (53.4 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 302 IP gateway (BSC)
BACnet gateway
Functions
The Automation Manager is BACnet-compatible via the BACnet gateway. The BACnet gateway enables easy integration of the Automation Manager in the building management system.
The Automation Manager and BACnet gateway communicate via the Schüco device bus or the integrated WiFi connection of the BACnet gateway. No additional power pack required.
Characteristics
Series installation device with 3 modules
Power supply 24 V DC
Prepared for connection to Schüco Automation Manager
The BACnet gateway meets the official ASHRAE standard
Contents of delivery
BACnet gateway in the series installation device with 3 modules
Operating instructions
Technical data
Power supply: 24 V DC
Bus connection (1): Ethernet
Bus connection (2): Schüco device bus by means of top hat rail adapter
Number of Automation Managers 1
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 3 modules (53.4 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 299 BACnet gateway (BSC)
Sensor interface
Functions
Enables the connection of max. 4 analogue sensors to the freely configurable inputs. Status LED indicates the system is ready for operation. Requires Schüco Automation Manager. Communication with the Automation Manager by means of the Schüco device bus. Settings via the display of the Automation Manager or via the Schüco Automation Engineering Tool software.
Up to four sensor interfaces can be operated on one Automation Manager. Can be combined with a KNX or IP gateway, for example. The power is supplied by means of the Schüco device bus, so an independent power pack is not required.
Sensors carry out automatic functions such as night-time cooling. When connecting the sensors, both the current (4-20 mA) and the voltage signals (0-10 V) can be evaluated. The settings for this are make in the Engineering Automation Tool software.
Characteristics
Series installation device with 3 modules
Connection using plug-in terminal screws
Prepared for connection to Schüco Automation Manager 263245 via device bus
A maximum of 4 sensor interfaces can be connected to one Automation Manager
Contents of delivery
Sensor interface in series installation housing with 3 modules
Operating instructions
Technical data
Power supply: 24 V DC (via the Automation Manager)
Bus connection: Schüco device bus
Number of sensors: Max. 4
Output: 2 outputs can be configured via the DIP switch
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 3 modules (53.4 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 298 sensor interface (BSC)eans of the Schüco device bus. Settings via the display of the Automation Manager or via the Schüco Automation Engineering Tool software.
Up to four sensor interfaces can be operated on one Automation Manager. Can be combined with a KNX or IP gateway, for example. The power is supplied by means of the Schüco device bus, so an independent power pack is not required.
Sensors carry out automatic functions such as night-time cooling. When connecting the sensors, both the current (4-20 mA) and the voltage signals (0-10 V) can be evaluated. The settings for this are make in the Engineering Automation Tool software.
Characteristics
Series installation device with 3 modules
Connection using plug-in terminal screws
Prepared for connection to Schüco Automation Manager 263245 via device bus
A maximum of 4 sensor interfaces can be connected to one Automation Manager
Contents of delivery
Sensor interface in series installation housing with 3 modules
Operating instructions
Technical data
Power supply: 24 V DC (via the Automation Manager)
Bus connection: Schüco device bus
Number of sensors: Max. 4
Output: 2 outputs can be configured via the DIP switch
Protection rating: IP 20 (installed in the distributor)
Dimensions (W x H x D): 3 modules (53.4 x 89 x 60) mm
Installation: On standardised profile track
Manufacturer: Schüco International KG
Type: 263 298 sensor interface (BSC)
- AluminiumBuilding Skin Control (BSC)
